Processador AMD Ryzen 9 6900HS: com GPU AMD Radeon 680M DE 12 NÚCLEOS
O Processador AMD Ryzen 9 6900HS é um CPU da nova geração, que pode ser encontrado em alguns Notebooks da nova geração. É um chip da AMD, que vai oferece uma alta velocidade de processamento para lidar com diversos TRABALHOS.
O Ryzen 9 6900HS tem oito núcleos, 16 threads e a frequência de clock é de até 4.9 GHZ.
O Cachê L3 total é de até 16 MB e tem suporte para PCIe 4.0. O Consumo de energia é de até 35W. Está versão do Processador pode gerenciar até dois canais de memória, gerencia até 64 Gigas e suporta memória compatível com os seguintes barramentos:
4x1R DDR5-4800
4x1R LPDDR5-6400
A Placa gráfica integrada é um AMD Radeon 680M, com 12 núcleos e a frequência de clock máxima é de 2400 MHz.
General Specifications
Platform
Laptop
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 9 Mobile Processors with Radeon™ Graphics
AMD PRO Technologies
No
Consumer Use
Yes
Regional Availability
Global, China, NA, EMEA, APJ, LATAM
Former Codename
“Rembrandt”
Architecture
“Zen 3+”
# of CPU Cores
8
Multithreading (SMT)
Yes
# of Threads
16
Max. Boost Clock
Up to 4.9GHz
Base Clock
3.3GHz
L1 Cache
512KB
L2 Cache
4MB
L3 Cache
16MB
Default TDP
35W
Processor Technology for CPU Cores
TSMC 6nm FinFET
CPU Compute Die (CCD) Size
210mm²
Package Die Count
1
Unlocked for Overclocking
No
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax)
95°C
*OS Support
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support
Yes
Native USB 3.2 Gen 2 (10Gbps) Ports
2
Native USB 3.2 Gen 1 (5Gbps) Ports
0
Native USB 2.0 (480Mbps) Ports
4
Native SATA Ports
0
PCI Express® Version
PCIe® 4.0
Native PCIe® Lanes (Total/Usable)
20/16
NVMe Support
Boot, RAID0, RAID1, RAID10
System Memory Type
DDR5
Memory Channels
2
Max. Memory
64GB
System Memory Subtype
UDIMM
Max Memory Speed
4x1R
DDR5-4800
4x1R
LPDDR5-6400
ECC Support
Yes (Requires mobo support)
Graphics Capabilities
Integrated Graphics
Yes
Graphics Model
AMD Radeon™ 680M
Graphics Core Count
12
Total Graphics Shaders
768
Graphics Frequency
2400 MHz
GPU Max. Memory
2GB
WDDM Version
2.7
DirectX® Version
12
OpenGL®
4.6
OpenCL™
2.2
DisplayPort™ Version
2
DisplayPort Extensions
HBR3
HDR Metadata
Adaptive-Sync
DisplayPort Max Refresh Rates (SDR)
3840×2160 @ 60Hz
3440×1440 @ 144Hz
2560×1440 @ 180Hz
1920×1080 @ 240Hz
DisplayPort Max Refresh Rates (HDR)
3840×2160 @ 60Hz
3440×1440 @ 144Hz
2560×1440 @ 180Hz
1920×1080 @ 240Hz
HDMI® Version
2.1
HDCP Version Supported
2.2
USB Type-C® DisplayPort™ Alternate Mode
Yes
Multi-Monitor Support
Yes
Max Displays
4
AMD FreeSync™
Yes
AMD Eyefinity Single Large Surface (SLS)
No
Wireless Display
Miracast
Max Video Encode Bandwidth (SDR)
1080p205 8bpc H.264
1440p115 8bpc H.264
2160p51 8bpc H.264
1080p205 8bpc H.265
1440p115 8bpc H.265
2160p51 8bpc H.265
Max Video Decode Bandwidth
1080p60 MPEG2
1080p60 VC1
1080p240 8bpc VP9
1080p240 10bpc VP9
1080p240 H.264
1080p240 8bpc H.265
1080p240 10bpc H.265
1080p240 JPEG 8bpc
Product IDs
Product ID Tray
FP7:100-000000544 FP7r7:100-000000560
Security, Virtualization, and Manageability
AMD Enhanced Virus Protection (NX bit)
Yes
