AMD Ryzen 9 6980HX: Processador AMD Ryzen 9 e Placa gráfica AMD Radeon 680M
O Processador AMD Ryzen 9 6980HX da nova Geração pode ser encontrado em diversos Notebooks atuais. É um CPU da AMD, que vai oferece uma alta PERFORMANCE e super velocidade para lidar com diversos projetos do dia a dia.
O Ryzen 9 6980HX tem oito núcleos, 16 threads e a frequência de clock é de até 5.00 GHZ.
O Cachê L3 total é de até 16 MB. O Consumo de energia é de até 45W. Está versão do Processador pode gerenciar até dois canais de memória, tem conexão PCIe® 4.0 e suporta memória compatível com os seguintes barramentos:
4x1R DDR5-4800
4x1R LPDDR5-6400
A Placa gráfica integrada é um AMD Radeon 680M, com 12 núcleos e a frequência de clock máxima é de 2400 MHz .
General Specifications
Platform: Laptop
Product Family: AMD Ryzen™ Processors
Product Line: AMD Ryzen™ 9 Mobile Processors with Radeon™ Graphics
AMD PRO Technologies: No
Consumer Use: Yes
Regional Availability: Global, China, NA, EMEA, APJ, LATAM
Former Codename: “Rembrandt”
Architecture: “Zen 3+”
# of CPU Cores: 8
Multithreading (SMT): Yes
# of Threads: 16
Max. Boost Clock: Up to 5.0GHz
Base Clock: 3.3GHz
L1 Cache: 512KB
L2 Cache: 4MB
L3 Cache: 16MB
Default TDP: 45W
Processor Technology for CPU Cores: TSMC 6nm FinFET
CPU Compute Die (CCD) Size: 210mm²
Package Die Count:1
Unlocked for Overclocking: Yes
CPU Socket: FP7
CPU Boost Technology: Precision Boost 2
Instruction Set: x86-64: Supported Extensions
AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax): 95°C
*OS Support
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support: Yes
Native USB 3.2 Gen 2 (10Gbps) Ports: 2
Native USB 3.2 Gen 1 (5Gbps) Ports:0
Native USB 2.0 (480Mbps) Ports: 4
Native SATA Ports: 0
PCI Express® Version: PCIe® 4.0
Native PCIe® Lanes (Total/Usable): 20/16
NVMe Support: Boot, RAID0, RAID1, RAID10
System Memory Type: DDR5
Memory Channels: 2
Max. Memory: 64GB
System Memory Subtype: UDIMM
Max Memory Speed: 4x1R DDR5-4800- 4x1R LPDDR5-6400
ECC Support: Yes (Requires platform support)
Graphics Capabilities
Integrated Graphics: Yes
Graphics Model: AMD Radeon™ 680M
Graphics Core Count: 12
Total Graphics Shaders: 768
Graphics Frequency: 2400 MHz
GPU Max. Memory: 2GB
WDDM Version: 2.7
DirectX® Version: 12
OpenGL®: 4.6
OpenCL™: 2.2
DisplayPort™ Version: 2
DisplayPort Extensions: HBR3
HDR Metadata
Adaptive-Sync
DisplayPort Max Refresh Rates (SDR):
3840×2160 @ 60Hz
3440×1440 @ 144Hz
2560×1440 @ 180Hz
1920×1080 @ 240Hz
DisplayPort Max Refresh Rates (HDR):
3840×2160 @ 60Hz
3440×1440 @ 144Hz
2560×1440 @ 180Hz
1920×1080 @ 240Hz
HDMI® Version: 2.1
HDCP Version Supported: 2.2
USB Type-C® DisplayPort™ Alternate Mode: Yes
Multi-Monitor Support: Yes
Max Displays: 4
AMD FreeSync™: Yes
AMD Eyefinity Single Large Surface (SLS): No
Wireless Display: Miracast
Max Video Encode Bandwidth (SDR):
1080p205 8bpc H.264
1440p115 8bpc H.264
2160p51 8bpc H.264
1080p205 8bpc H.265
1440p115 8bpc H.265
2160p51 8bpc H.265
Max Video Decode Bandwidth:
1080p60 MPEG2
1080p60 VC1
1080p240 8bpc VP9
1080p240 10bpc VP9
1080p240 H.264
1080p240 8bpc H.265
1080p240 10bpc H.265
1080p240 JPEG 8bpc
Product IDs
Product ID Tray
FP7:100-000000750 FP7r2: 100-000000751
Security, Virtualization, and Manageability
AMD Enhanced Virus Protection (NX bit): Yes
